ABUS DTS2814 Wireless Door/Window Contact - White ABTS01644

Secure your premises with the ABUS DTS2814 wireless magnetic contact sensor, operating at 868.6625 MHz for reliable communication with ABUS Secvest alarm systems. This surface-mount sensor detects unauthorized opening of doors or windows, providing an essential layer of perimeter protection.

Overview

The DTS2814 combines a transmitter unit and a magnet unit in a discreet white ABS housing. Powered by two AAA alkaline batteries, it offers a battery life of 2-3 years, minimizing maintenance. The sensor features tamper protection and low-battery indication, ensuring continuous security awareness.

What stands out

• Wireless range up to 30 meters indoors, allowing flexible placement.
• Simple installation with adhesive tape or screws (self-adhesive tape included).
• LED status indicator for battery and operational state.
• Compatible with ABUS Secvest alarm systems for seamless integration.

Technical details

• Operating frequency: 868.6625 MHz
• Power source: 2x AAA 1.5V alkaline batteries
• Battery life: approximately 2-3 years
• Wireless range: up to 30 m indoors
• Operating temperature: -10°C to +50°C
• Relative humidity: max 95% non-condensing
• Housing material: ABS plastic
• Colour: white
• Detection method: magnetic contact
• Tamper protection: yes
• Low battery indication: yes
• Installation type: surface mount (adhesive/screws)
• Magnet unit dimensions: 40 x 10 x 10 mm

Our verdict

The ABUS DTS2814 is a dependable choice for expanding your Secvest system's intrusion detection, offering straightforward installation and long battery life.
