FlashForge AD5X IFS Feed Wheel (20004782001)

Keep your FlashForge Adventurer 5M or 5M Pro printing reliably with this replacement extruder feeding wheel. It is the drive gear that grips and pushes filament through the direct-drive extrusion system, and it is a direct replacement for the original part (20004782001).

Key specifications

• Type: Extruder Feeding Wheel
• Compatibility: FlashForge Adventurer 5M, Adventurer 5M Pro
• Material: Hardened Steel
• Inner Diameter: 5 mm
• Outer Diameter: 11.5 mm
• Height: 11.5 mm
• Installation: Press-fit onto motor shaft
• Colour: Metallic Silver/Grey

Why choose it

Over time, the feeding wheel can wear or clog, causing under-extrusion or filament slipping. This hardened steel gear restores consistent filament feeding, so your prints come out clean and accurate. It is made to the same specifications as the part that came with your printer.

Ideal use cases

• Replacing a worn or damaged feeding wheel on an Adventurer 5M or 5M Pro
• Restoring reliable extrusion after filament jams or grinding
• Keeping a spare part on hand for quick maintenance

Good to know

This is a genuine FlashForge part (20004782001). It fits all standard FDM filaments, including PLA, ABS, PETG, and TPU. Press-fit installation requires no special tools, but take care to align it correctly on the motor shaft.
