Gira System 106 outdoor camera module 122000

Camera module for the Gira System 106 door communication system, delivering HD video with automatic day/night switching and integrated IR illumination for clear images even in complete darkness.

Advantages

High-resolution 1280 x 720 pixel color CMOS sensor with wide-angle lens captures a horizontal field of view of approximately 90°, ensuring visitors are clearly visible. Automatic day/night switching via light sensor and integrated IR LEDs provide reliable night vision down to 0 Lux. Compact module integrates seamlessly into Gira System 106 housings, powered directly by the system bus.

Suitable for

• Gira System 106 door stations
• Residential and commercial entrance monitoring
• Retrofit and new installations using System 106 modular components

Key specifications

• Resolution: 1280 x 720 pixels (HD)
• Horizontal detection angle: approx. 90°
• Vertical detection angle: approx. 70°
• Minimum illumination: 0.1 Lux (color), 0 Lux (B/W with IR)
• Operating temperature: -25 °C to +70 °C
• Protection class: IP54 (when installed in System 106 housing)
• Module color: Black
• Front plate dimensions (H x W): 106.5 x 106.5 mm
• Module depth: approx. 32 mm

Recommendations

For optimal performance, install the module in a Gira System 106 housing and ensure proper alignment for the desired field of view. The module is powered via the system bus, eliminating the need for separate power wiring.
