HellermannTyton 162-20200 Floor Cable Duct Black 1m PVC Self-Adhesive

Protect cables in high-traffic areas with this low-profile PVC floor cable protector from HellermannTyton. Its self-adhesive backing secures it to floors, while the internal channel routes cables safely underfoot.

Overview

The HellermannTyton 162-20200 is a black PVC floor cable protector designed to cover and protect cables on the floor. It measures 1000 mm in length, 40 mm in width, and 10 mm in height, with an internal channel of 20 mm width and 7 mm height. The self-adhesive tape on the underside allows for easy installation on clean, flat surfaces. Suitable for indoor use in offices, commercial spaces, and homes, it can accommodate multiple data or power cables, such as 2-3 standard network cables.

What stands out

• Low-profile design minimizes trip hazard
• Self-adhesive backing for quick installation
• Durable PVC construction withstands foot traffic
• Self-extinguishing material for added safety
• Good chemical resistance to common acids, alkalis, and oils

Technical details

• Material: PVC
• Colour: Black
• Length: 1000 mm
• External width: 40 mm
• External height: 10 mm
• Internal channel width: 20 mm
• Internal channel height: 7 mm
• Number of channels: 1
• Mounting method: Self-adhesive
• Temperature range: -20 °C to +60 °C
• Flame retardancy: Self-extinguishing
• UV resistance: Limited (indoor use)
• Impact resistance: Good for foot traffic
• Chemical resistance: Good against common acids, alkalis, and oils
• RoHS compliance: Yes
• Halogen-free: No

Our verdict

A practical solution for keeping cables safe and organized in busy areas, combining durability with easy installation.
