HellermannTyton Q-Mount Self-Adhesive Cable Tie Mount Black (148-00098)

The HellermannTyton 148-00098 Q-Mount offers a self-adhesive solution for securing cable ties without drilling. Its compact 19 x 19 mm footprint suits tight spaces where screw-mounted bases are impractical.

Highlights

• Self-adhesive backing for quick, tool-free installation
• Made from durable Polyamide 6.6 (PA66)
• Accepts cable ties up to 4.8 mm wide
• Black colour blends into most equipment

In daily use

Peel off the liner and press the mount onto a clean, flat surface. The synthetic rubber adhesive bonds to metal, plastic, and painted surfaces. Once set, thread a cable tie through the slot to bundle wires securely. The mount is rated for indoor use and withstands temperatures from -40°C to +85°C.

Full specifications

• Product Type: Cable Tie Mount
• Mounting Method: Self-Adhesive
• Material: Polyamide 6.6 (PA66)
• Colour: Black
• Length: 19 mm
• Width: 19 mm
• Height: 4.5 mm
• Max. Cable Tie Width: 4.8 mm
• Operating Temperature Range: -40°C to +85°C
• Adhesive Type: Synthetic Rubber
• Adhesive Application Temperature Range: -20°C to +65°C
• Flammability Rating: UL94 V2
• RoHS Compliant: Yes
• Halogen-free: Yes
• Indoor/Outdoor Use: Indoor
• Static Load Capacity (Adhesive): 2.5 N (approx. 0.25 kg)
• Series: Q-Mount
• Adhesive Backing: Yes

Final note

For reliable cable management in control panels, enclosures, and office equipment, the Q-Mount provides a clean and permanent fixing point.
