Lanberg WF01-6618-10S Wall-Mountable Rack

In a busy small business server room, every square metre counts. The Lanberg WF01-6618-10S wall-mounted rack frees up floor space while keeping 18U of 19-inch equipment secure, organised, and easily accessible. Its grey RAL 7035 finish blends into professional environments, and the lockable front door with 180° rotation plus removable side panels make maintenance straightforward.

Key specifications

• Rack capacity: 18U for 19-inch equipment
• Maximum load capacity: 60 kg
• External dimensions: 600 × 600 × 907 mm (W × D × H)
• Weight: 30 kg
• Material: high-grade cold-rolled steel
• Colour: grey (RAL 7035)
• Protection rating: IP20
• Front door: lockable, rotates up to 180°
• Side panels: removable with locks
• Cable entry: top and bottom panels
• Mounting standard: 19-inch adjustable rails
• Included accessories: rail mounts, M6 cage nuts, blank entry panels
• Assembly: flat-pack, self-assembly required

Why choose it

This rack is built from sturdy steel to support up to 60 kg of networking gear, and its compact footprint keeps equipment off the floor. The lockable door and side panels deter unauthorised access, while top and bottom cable entries allow clean routing. Supplied flat-packed with all necessary hardware, it is ready to assemble and mount on a suitable wall.

Ideal use cases

• Mounting 19" network switches, patch panels, and routers
• Small server or network equipment installations (18U capacity)
• CCTV, IP surveillance, and access control systems
• Cable television, alarm, and fire protection low-voltage systems
• Server rooms, small and medium businesses, and distributed network installations

Good to know

The cabinet has an IP20 rating, suitable for indoor use in controlled environments. Passive ventilation openings help maintain airflow. Optional 120 mm fan support is available for additional cooling if needed. Assembly instructions are included, and the unit must be secured to a wall structure using appropriate anchors for the wall material.
