TechniSat 0100/3337 F-Type Compression Plug (100-Pack)

Coaxial connections in satellite and cable TV installations often suffer from signal loss or corrosion when terminated with low-quality connectors. The TechniSat 0100/3337 F-type compression connector solves this by providing a secure, waterproof, and UV-resistant termination for coaxial cables. Sold in a bulk pack of 100, these connectors are built for professional installers and demanding DIY projects.

Who is it for

Satellite and cable TV installers, network technicians, and advanced home users who need reliable, high-performance F-type connectors for outdoor or indoor coaxial cable terminations. Ideal for DVB-T/T2, satellite (SAT), and cable TV (CATV) applications.

Main features

• Compression connection method for a secure, permanent fit
• F-type connector with 75 Ohm impedance
• Brass construction with nickel plating for corrosion resistance
• Waterproof and UV-resistant design for outdoor durability
• Shielding class A+ for excellent signal integrity
• Supports frequencies up to 3000 MHz
• Compatible with coaxial cables with 7.0-7.2 mm outer diameter (e.g., RG6)
• Bulk pack of 100 pieces

Specifications

• Connector type: F-type
• Connection method: Compression
• Impedance: 75 Ohm
• Material: Brass, nickel-plated
• Shielding class: Class A+
• Weather resistance: Waterproof, UV-resistant
• Frequency range: 0 - 3000 MHz
• Return loss: > 30 dB (up to 1 GHz)
• Insertion loss: < 0.1 dB (up to 1 GHz)
• Operating temperature: -40°C to +60°C
• Mounting type: Cable mount
• Quantity: 100 pieces

Tips

Use a dedicated F-compression tool to ensure a proper crimp and maintain the connector's waterproof seal. For outdoor installations, pair with weatherproof boots for added protection.
